Raws li qhov tseeb cov ntaub ntawv loj tshaj plaws ntawm kev lag luam aluminium composite vaj huam sib luag, qhov kev thov rau hyperbolic aluminium puas vaj huam sib luag yog tsis tu ncua ntawm kev loj hlob txhua xyoo. Lawv cov qauv tsim tshwj xeeb ua rau lawv nrhiav tau ntau heev- tom qab cov khoom siv kho kom zoo nkauj, nyiam dav thiab xaiv los ntawm cov tswv thiab cov tsim qauv.
Vim li cas hyperbolic aluminium composite panels thiaj li nrov?
Ua ntej, hyperbolic aluminium composite panels tau txais cov khoom tshwj xeeb thiab zoo tshaj plaws nyob rau hauv aluminium composite panels. Thib ob, lawv cov duab ntau yam tso cai rau kev tsim kho thiab kev ua haujlwm kom tau raws li qhov xav tau ntawm curvature, ua kom paub tseeb cov neeg tsim qauv cov tswv yim tsim vaj tsev thiab muab cov tsev zoo nkauj zoo nkauj thiab pom kev ntxim nyiam.
Khoom yam ntxwv
Muaj cov khoom tshwj xeeb thiab zoo tshaj plaws ntawm txhuas vaj huam sib luag: lub teeb yuag, nruj, tsis muaj plua plav, ya raws- pov thawj, hluav taws kub, corrosion{1}} tiv taus, huab cua- tiv taus, lub neej ua haujlwm ntev, thiab zoo heev UV tiv taus thiab cua siab;
Muaj ntau hom kev ntxhib los mos thiab xim muaj, muab cov teebmeem zoo nkauj zoo nkauj;
Ntau yam duab qhia txog kev zoo nkauj ntawm kev tsim nkhaus;
Tib neeg -tus qauv tsim qauv, yooj yim rau kev sib sau thiab disassemble, yooj yim installation thiab tsim;
Yooj yim txij nkawm thiab hloov pauv, hloov tau yooj yim rau kev hloov kho;
Tsawg kub ntxhov siab; thaum txuas nrog lwm cov ntaub ntawv xws li iav, hlau, thiab pob zeb siv cov ntaub ntawv hloov tau yooj yim, nws tuaj yeem txo qhov kub thiab txias los ntawm kev hloov kub ntawm cov qauv.
Yam khoom
Cov hom muaj xws li spherical, hemispherical, twisted ob - khoov, thiab ib zaug - khoov vaj huam sib luag, nyob ntawm lawv qhov curvature thiab cov duab.
Khoom Specifications
Standard Flat Vaj Huam Sib Luag Loj: 600 × 1200 mm, 600 × 1500 mm, 1000 × 2000 mm
Qhov siab tshaj plaws Vaj Huam Sib Luag Loj: 1200 × 2400 mm (lwm qhov loj tuaj yeem welded)
Standard Thickness: 2.0-3.0 hli
Qhov siab tshaj plaws Thickness: 5.0mm
Ua Technology thiab Installation Points
Hyperbolic aluminium panels yog prefabricated panels uas yuav tsum tau ua ntej - tsim nyob rau hauv lub Hoobkas thiab ces sib sau ua ke ntawm - qhov chaw raws li kos duab. Yog li ntawd, hyperbolic aluminium panels yuav tsum tau siab precision nyob rau hauv Hoobkas prefabrication.
1. Kev Siv Tshuab
Kev ua thiab kev tsim cov txheej txheem rau hyperbolic txhuas vaj huam sib luag muaj xws li tuag stretching forming, sib sau siv ib tug multi-point forming xovxwm, ib tug - sij hawm stamping txoj kev nrog ib tug neeg kho tshuab hlau pwm, saj zawg zog yob txoj kev, thiab nyob rau hauv - site forming.
① Tuag Stretching forming
Qhov no yog txoj hauv kev zoo tshaj plaws rau kev ua cov hlau nplaum hyperbolic. Ua ntej, pwm yog ua tib zoo ua raws li cov qauv tsim tshwj xeeb; Tom qab ntawd, lub vaj huam sib luag aluminium yog ruaj khov thiab ruaj khov rau cov pwm no siv roj hmab. Tom qab ntawd, cov neeg ua haujlwm ua tib zoo coj mus rhaub lub vaj huam sib luag txhuas kom nws haum nruj rau pwm nto. Tom qab qhov kev ntxhov siab sab hauv ntawm cov ntawv txhuas tau tso tawm tag nrho, cov npoo thiab cov ces kaum raug txiav kom tshem tawm qhov ntau dhau lossis qhov tsis sib xws, thaum kawg tau txais daim ntawv txhuas nkhaus uas zoo kawg nkaus phim cov qauv tsim.
Kev kho pwm feem ntau yog ua los ntawm cov ntoo, yas, hlau, thiab lwm yam. Cov yam ntxwv ntawm pwm stretching forming yog tsim rau kev tsim loj batch ntawm txhuas ntawv nrog tib curvature. Nws muaj kev sib sau ceev ceev thiab siab precision. Qhov tsis zoo yog tus nqi siab ntawm kev tsim pwm, ua rau nws tsis tsim nyog rau cov khoom me me ntawm ntau hom nkhaus hlau qhov chaw.
② Ntau-point Forming Press Forming
Cov pwm no muaj cov ntsiab lus tsis sib xws uas nws txoj haujlwm yog kho tau, tso cai rau cov pwm rov siv dua thiab cov khoom me me yuam kev. Txawm li cas los xij, nws yog kim thiab haum rau me me batch ntau lawm.
③ Ib -lub sij hawm Stamping Forming nrog Mechanical Hlau Pwm
Cov pwm hlau feem ntau muab faib ua pwm sab sauv thiab qis. Lawv raug tsim nyob rau hauv ib kauj ruam siv tshuab cuab yeej hydraulics. Ib qho - lub sij hawm tsim pwm tso cai rau ntau lawm, tab sis cov kev txwv ntawm pwm tsim lub voj voog thiab tus nqi ua rau nws tsis tsim nyog rau cov khoom me me ntawm qhov tsis sib xws.
Multi-point forming mold technology kuj tau nkag mus rau hauv lub tshuab cuab yeej pwm teb. Cov cuab yeej no tuaj yeem tsim cov ntawv hlau nkhaus hauv ib kauj ruam thiab hloov tau yooj yim dua ntawm cov khoom siv thiab cov khoom kom muaj nuj nqis. Los ntawm kev xa cov qauv tsim rau hauv lub computer, cov txheej txheem ntau lawm tuaj yeem ua tiav sai, ua kom cov khoom lag luam siab. Txawm li cas los xij, vim yog tus nqi siab ntawm ntau- taw tes ua cov cuab yeej siv tshuab, lawv tam sim no kuj tsis tshua muaj nyob hauv Suav teb.
④ Yooj yim yob txoj kev
Nws cov yam ntxwv tseem ceeb nyob rau hauv kev khoov muaj peev xwm ntawm kev ua haujlwm yob axis, thiab qhov kev khoov no tuaj yeem tswj tau thiab kho raws li qhov xav tau tiag tiag. Thaum lub sij hawm tsim cov txheej txheem, cov ntaub ntawv uas yuav tsum tau ua tiav yog nruj nreem clamped ntawm kev ua hauj lwm yob, uas tig synchronously nyob rau hauv lub tsav mechanism, tsav lub workpiece rau noj. Cov txheej txheem no ua rau kev ua haujlwm yob yob cov ntaub ntawv, uas ua rau cov yas deformation nyob rau hauv ob qho tib si longitudinal thiab transverse cov lus qhia, ua rau nws tsim nyog rau kev tsim cov ntawv txhuas nrog ntau yam nkhaus nkhaus. Txawm li cas los xij, cov cuab yeej siv rau cov cuab yeej siv no yog siab, thiab kev saib xyuas thiab kev kho cov cuab yeej siv kuj raug nqi tseem ceeb.
⑤ Ntawm -Site Forming
Ntawm -qhov chaw tsim tshuab yog tshwj xeeb yog tsim rau kev tsim cov txhuas vaj huam sib luag nrog loj radii. Ua ntej, cov ntaub ntawv sab nraub qaum yog xam kom raug siv cov software tshwj xeeb, thiab raws li qhov no, qhov chaw dai ntawm txhua daim ntawv txhuas yog qhov tseeb. Tom ntej no, steel reinforcement joists tau teeb tsa los txhawb cov qauv kev txhawb nqa rov qab, thiab nkhaus aluminium raj tau teeb tsa ntawm cov nodes tseem ceeb raws li kev siv "kab kav." Tom qab ntawd, cov neeg ua haujlwm tsim kho tau kho thiab kho cov ntawv txhuas raws li "kab kav," kom ntseeg tau tias haum. Txoj kev no txo qis cov nqi tsim khoom, tab sis sib raug zoo, nws muab qhov xav tau siab heev ntawm kev teeb tsa zoo thaum lub sijhawm ntawm - qhov chaw tsim kho.
