Khoom Description
Hauv kev tsim lub tsev niaj hnub-tshwj xeeb tshaj yog rau villas, tsev loj, lossis siab -kawm kawg- muaj kev tshaib plab loj rau lub qhov rooj uas tsis yog zoo nkauj xwb tab sis kuj ua haujlwm zoo heev. Cov neeg xav tau lub hnub ci ntau dua, pom qhov pom tseeb dua, thiab lub qhov rooj uas tuaj yeem tswj tau txhua qhov chaw ib puag ncig-xws li cov chaw ntug hiav txwv uas muaj huab cua qab ntsev lossis cov chaw tsis muaj av nrog huab cua vwm. Thiab cia peb tsis txhob hnov qab txog kev ruaj ntseg thiab kev siv hluav taws xob zoo- cov teeb meem ntau heev.
Ib feem tsis thiab configurations
| Thaj chaw | Pem teb qhov siab (m) | Cov qauv siv tau thiab qhov siab tshaj plaws ntawm qhov rooj ncej (mm) | Qhov siab tshaj plaws ntawm qhov rooj ncej (mm) |
|---|---|---|---|
| Ntug hiav txwv (A) | Tsawg dua los yog sib npaug li 10 | DU135, Tsawg dua lossis sib npaug rau 2800 | Infinity |
| Ntug hiav txwv (A) | 10 - 60 | DU135, Tsawg dua lossis sib npaug rau 2800 | Infinity |
| Tsis muaj av (C) | Tsawg dua los yog sib npaug li 10 | DU135, Tsawg dua lossis sib npaug rau 2800 | Infinity |
| Tsis muaj av (C) | 10 - 60 | DU135, Tsawg dua lossis sib npaug rau 2800 | Infinity |
| Khoom ua haujlwm | DU135 |
|---|---|
| Profile qauv | Choj tawg |
| Hluav taws xob | √ |
| 90℃kaum sab xis tsis muaj kab | √ |
| iav tiv thaiv laj kab | √ |
| Nthuav mesh | √ |
| Taug qab pre embedded obstacle dawb | √ |
| Lub sab rail npog phaj yog sib xws nrog ceramic pobzeb thiab ntoo flooring | √ |
| RC3 peb - qib anti pry locking system | √ |
| Split sab sauv | √ |
| iav thickness | 34mm ib |
Nta & Cov txiaj ntsig
- Muaj zog Aluminium Profile: Tag nrho lub qhov rooj siv 6063-T6 aluminium alloy. Cov khoom siv no muab lub qhov rooj loj rau lub zog, yog li nws ruaj khov thiab tuaj yeem muaj sia nyob txawv huab cua yam tsis tau khoov lossis tawg.
- Sab saum toj -Tier Sealing System: Tus kheej -lubricating, qis- kev sib txhuam sealing yog txaus. Nws muaj ntau cov ntsaws ruaj ruaj, yog li dej nyob twj ywm tawm tag nrho, thiab cua tsis tuaj yeem nkag mus. Ntxiv rau, ib zaug sib sau ua ke, cov khoom siv roj hmab zoo nkauj ntawm cov iav sab yog du thiab huv si - tsis muaj kab txawv txawv thaiv koj qhov kev pom.
- Smooth -Sliding Pulleys: Muaj ntau qhov sib txawv ntawm kev teeb tsa rau ntau hom kev sib txawv thiab qhov rooj qhov hnyav. Peb siv cov ntaub ntawv zoo li stainless hlau thiab POM tshwj xeeb nylon, yog li lub qhov rooj swb yooj yim rau xyoo tsis tau daig lossis hnav sai.
- Kev Ruaj Ntseg Xauv Xaiv: Koj tau txais ob txoj kev xaiv ntawm no-RC3 tiv thaiv- tub sab tub nyiag thiab ntau-point xauv.
- Ntse Kab Screens: DU135 los nrog ob hom kab tshuaj ntsuam - ywj siab thiab zais. Qhov zais cia muaj ib txoj kab ntsug pom qhov dav uas tsuas yog 98mm dav, yog li nws khaws cov kab mob tawm yam tsis ua rau koj pom.
- Sturdy iav & Kev nyab xeeb: Lub iav yog 34 hli tuab - super khov. Kuj tseem muaj iav tiv thaiv kev xaiv, yog li koj nyob nyab xeeb yam tsis tau poob qhov qhib, panoramic vibe.
- Yooj yim khiav xaiv: Koj tuaj yeem xaiv ntawm phau ntawv los yog hluav taws xob sab sauv. Cov phau ntawv yog sleek (tsuas yog 60 hli siab), thiab hluav taws xob (125 hli siab) ntxiv yooj yim rau lub qhov rooj loj.
